Mother of the ancient gods and our first model designed.
Confort, stability and versatility at its finest.
We wanted this model to be reliable, light weighted and beautiful to look at in its simplicity.
The premium italian chestnut body and the roasted ash neck are the real stars, while the richlite fretboard with stainless steel frets, the handmade pickups and the proprietary headless tuning system are the best companions it could have.
Like many other models the multiscale is a key feature, the only way to achieve stable tension accross the entire fretboard, especially in low tuning contexs.
We worked to make this instrument attractive to look and easy to take around.
HIGHLIGHTS
MAIN SPECS
| Number of strings | 6 • 7 |
| General construction | Bolt-On |
| Scale lenght | Multiscale 25.5"/27" |
| Body woods | Italian chestnut |
| Fretboard woods | Richlite |
| Neck woods | Roasted flamed ash with carbon reinforcement |
| Neck dimensions & shape | 6 STRINGS Width: 43mm at nut - 53mm at 12th fret Thickness: 21mm at 1st fret - 22.5mm at 12th fret 7 STRINGS Width: 49mm at nut - 60mm at 12th fret Thickness: 20mm at 1st fret - 22mm at 12th fret |
| Number of frets | 24 |
| Type of frets | Jescar 47104 Stainless Steel |
| Fret markers | Pearl 4mm dots on the fretboard and 3mm luminlay on the side |
| Tuning machines | Hipshot Grip-Lock |
| Bridge | Hipshot Fixed bridge |
| Pickups | Gorilla custom |
| Knobs | Metal dome |
| Strap Pins | Schaller Security Locks |
| Controls | Volume, Tone, 3 way pickup selector |
| Hardware color | Black |
| Body, top & neck color | Erotic Nightmare / Blue Marine / Jungle Green - See them on the color chart |
| Body, top & neck finish | Open grain satin acrylic finish on all the instrument |
| Pickguard | Available on request |
| Tuning & Strings | E standard tuning 10 - 13 - 17 - 26 - 36 - 46 - 62 |
| Case | Overload hard foam custom bag |
Volume
Pickup Selector
Tone
Jack In →
GALLERY
Bianco
